N-Vision Nox35 640 2.5-20x 35mm Thermal Scope

Rated 0 out of 5
(be the first to review)

$6,795.00

Only 1 Available!

SKU: NVIS-NOX35 Categories: , , Tag: Brand:

Description

Nox35 is a 12-micron 60 Hz small, light, and fully functional thermal weapon sight that can serve double duty as a head-mounted monocular or a scanner. When you need a thermal weapon sight that lets you move from rifle to helmet or hand-held use with ease, look no further than N-Vision Nox. This unique product is proudly designed and built in the USA, using the best commercially available 640 x 480 60 Hz BAE thermal imaging core and the highest grade optical components.

Nox features a manual focus, non-rotating wide field of view 35mm F1.1 Germanium Lens to provide the best image quality in any weather conditions. Weapon and dovetail mounts are removable to reduce the unit’s size and weight to help achieve optimal NOX configuration.

Each Nox ships with a standard CR123 battery, rechargeable 18650 battery and a charger. Depending on ambient temperature, you can expect up to an hour of run time with a standard CR123 battery and four to seven-plus hours on the rechargeable 18650 battery.

Nox’s five ergonomic control buttons permit immediate access to calibration, polarity, zoom, photo, power and user-friendly menu system for zeroing and customizing device parameters. The dedicated calibration button gives the user ability to calibrate the unit with one hand in under one second.

Features:

  • 640×480 resolution, 12µm pixel pitch core
  • 1,491 Yard detection range on human sized targets
  • 2.5x Base Magnification
  • 1x, 2x, 4x, and 8x Digital Zoom
  • 12.2° x 9.3° Degree Field of View
  • 60HZ Refresh Rate





Specifications:

Microbolometer Resolution, pixels
640×480



Pixel Pitch, µm
12



Frame Rate, Hz
60



Magnification
2.5-20



Digital Zoom
1x / 2x / 4x



Lens Focus, mm
35



Spectral Sensitivity, µm
7.5-13.5



Relative aperture, D/f'
1:1.1



Field of View, degrees
12° x 9°



Battery Type
1 CR 123 or 1 18650



Operating Temperature
-40F to 122F



Weight
16.9 ounces (no weapon mount), 19.3 ounces (weapon mount)



Length
6.8″



Width
2.9″



Height
2.4″



Warranty
5 Years



Gallery



Additional information

Weight7.6 lbs
Dimensions14 × 14 × 12 in
