Pulsar Axion Key XM30 2.4-9.6×24 Thermal Monocular
$1,600.00
At just 8.8 ounces and small enough to carry in your pocket or pack, the Pulsar Axion Key XM30 Thermal Monocular is proof that big performance can come in a small package. The Axion Key XM30 is built for reliable use, even in adverse conditions, with an all-metal, magnesium-alloy body and is waterproof rated IPX7, submersible in 3 feet of water for up to 30 minutes.
Only 1 Available!
Description
At just 8.8 ounces and small enough to carry in your pocket or pack, the Pulsar Axion Key XM30 Thermal Monocular is proof that big performance can come in a small package. The Axion Key XM30 is built for reliable use, even in adverse conditions, with an all-metal, magnesium-alloy body and is waterproof rated IPX7, submersible in 3 feet of water for up to 30 minutes. Performance comes in the form of an advanced 320×240 microbolometer sensor with 12μm pixel pitch for improved imaging at increased magnification and in adverse conditions, 960×720 LCOS micro-display, 8-color imaging palette, 2.5-10x magnification, picture-in-picture, easy user interface, instant startup and an extended 1,400-yard heat-signature detection range.
Features:
- 320×240 resolution, 12um pixel pitch core
- LCOS display
- 4x digital zoom – continuous zoom and 2x, 4x stepped zoom
- Lightweight and rugged magnesium allow housing
- Picture in picture digital zoom
- Multiple color viewing modes
- Stadiametric rangefinder
- IPX7 waterproof rated
Included:
- USB cable
- Hand strap
- Lens Cleaning Cloth
- Carrying Case
Batteries Required:
- 1xAPS 3 (Li-Ion) Battery Pack Batteries
Frame Rate, Hz 50 |
Microbolometer Resolution, pixels 320×240 |
Sensor response LWIR |
Spectral Sensitivity, µm 8-14 |
Pixel Pitch, µm 12 |
Display Type LCOS |
Display Resolution, pix. 960×720 |
Built-in Video Recorder Availability No |
Micro USB Socket Power |
Operating modes Rocks, Forest, Identification |
Integrated Wi-Fi No |
Defective Pixel Repair Option Yes |
Stadiametric Rangefinder Yes |
Multiple color palettes Yes |
Stream Vision support No |
Magnification 2.5 – 10 |
Digital Zoom 4x |
Lens diameter, mm 30 |
Lens Focus, mm 30 |
Relative aperture, D/f' 1:1.2 |
Field of View, degrees 7.3 |
Minimum focusing distance, ft/m 10 / 3 ft / m |
Eye Relief 14 mm |
Exit Pupil, mm 3 |
Diopter Adjustment ± 5 |
Focusing Type of Distance Objective |
Range of Detection 1400 / 1300 yd / m |
Power Supply 3 – 4.3 V |
Battery Type APS 3 (Li-Ion) |
Battery life, (with video out off), hours 4 |
External Power Supply 5V MicroUSB |
Physical & operational characteristics, Lens Material Germanium |
Body Material Magnesium alloy |
Tripod Mount, inch 1/4 |
Operating Temperature -13 to 104 / -25 to +40 F / C |
Level of Protection (acc. to IEC 60529) IPX7 |
Calibration Manual, Automatic, Semi-automatic |
Length 5.6 / 143 in / mm |
Physical & operational characteristics, Width 1.6 / 41 in / mm |
Height 2.7 / 69 in / mm |
Weight, oz 8.8 oz |
Additional information
| Weight | 1.5 lbs |
|---|---|
| Dimensions | 12 × 12 × 8 in |
