Pulsar Axion Key XM30 2.4-9.6×24 Thermal Monocular

Rated 0 out of 5
(be the first to review)

Original price was: $2,089.99.Current price is: $1,600.00.

At just 8.8 ounces and small enough to carry in your pocket or pack, the Pulsar Axion Key XM30 Thermal Monocular is proof that big performance can come in a small package. The Axion Key XM30 is built for reliable use, even in adverse conditions, with an all-metal, magnesium-alloy body and is waterproof rated IPX7, submersible in 3 feet of water for up to 30 minutes.

Only 1 Available!

SKU: NGI-PULSAR-AXION-KEY-XM30 Categories: , , Tag: Brand:

Description

At just 8.8 ounces and small enough to carry in your pocket or pack, the Pulsar Axion Key XM30 Thermal Monocular is proof that big performance can come in a small package. The Axion Key XM30 is built for reliable use, even in adverse conditions, with an all-metal, magnesium-alloy body and is waterproof rated IPX7, submersible in 3 feet of water for up to 30 minutes. Performance comes in the form of an advanced 320×240 microbolometer sensor with 12μm pixel pitch for improved imaging at increased magnification and in adverse conditions, 960×720 LCOS micro-display, 8-color imaging palette, 2.5-10x magnification, picture-in-picture, easy user interface, instant startup and an extended 1,400-yard heat-signature detection range.

Features:

  • 320×240 resolution, 12um pixel pitch core
  • LCOS display
  • 4x digital zoom – continuous zoom and 2x, 4x stepped zoom
  • Lightweight and rugged magnesium allow housing
  • Picture in picture digital zoom
  • Multiple color viewing modes
  • Stadiametric rangefinder
  • IPX7 waterproof rated

Included:

  • USB cable
  • Hand strap
  • Lens Cleaning Cloth
  • Carrying Case

Batteries Required:

  • 1xAPS 3 (Li-Ion) Battery Pack Batteries
Frame Rate, Hz
50
Microbolometer Resolution, pixels
320×240
Sensor response
LWIR
Spectral Sensitivity, µm
8-14
Pixel Pitch, µm
12
Display Type
LCOS
Display Resolution, pix.
960×720
Built-in Video Recorder Availability
No
Micro USB Socket
Power
Operating modes
Rocks, Forest, Identification
Integrated Wi-Fi
No
Defective Pixel Repair Option
Yes
Stadiametric Rangefinder
Yes
Multiple color palettes
Yes
Stream Vision support
No
Magnification
2.5 – 10
Digital Zoom
4x
Lens diameter, mm
30
Lens Focus, mm
30
Relative aperture, D/f’
1:1.2
Field of View, degrees
7.3
Minimum focusing distance, ft/m
10 / 3 ft / m
Eye Relief
14 mm
Exit Pupil, mm
3
Diopter Adjustment
± 5
Focusing Type of Distance
Objective
Range of Detection
1400 / 1300 yd / m
Power Supply
3 – 4.3 V
Battery Type
APS 3 (Li-Ion)
Battery life, (with video out off), hours
4
External Power Supply
5V MicroUSB
Physical & operational characteristics, Lens Material
Germanium
Body Material
Magnesium alloy
Tripod Mount, inch
1/4
Operating Temperature
-13 to 104 / -25 to +40 F / C
Level of Protection (acc. to IEC 60529)
IPX7
Calibration
Manual, Automatic, Semi-automatic
Length
5.6 / 143 in / mm
Physical & operational characteristics, Width
1.6 / 41 in / mm
Height
2.7 / 69 in / mm
Weight, oz
8.8 oz

Additional information

Weight1.5 lbs
Dimensions12 × 12 × 8 in
